5. Administration

Working Mode

Use this section to set the working mode parameters.

 Enable ICMP so that the CN8000A can be pinged. If it is not enabled, the

device cannot be pinged. The default is Enabled.

 Enable Multiuser Operation to permit more than one user to log into the

CN8000A at the same time. The default is Enabled.

 Enable Virtual Media Write allows redirected virtual media devices on a

user’s system to send data to a remote server, as well as being able to have

data from the remote server written to them. The default is Enabled.

 Browser Service allows the administrator to limit the scope of browser

access to the CN8000A. Put a check in the checkbox to enable this

function, then select the browser limitation in the drop down list box.

Choices are explained in the following table:

 If Disable Authentication is checked, no authentication procedures are

used to check users attempting to log in. Users gain Administrator access

to the CN8000A switch simply by entering combination of username and

password.

Note: Enabling this setting creates an extremely dangerous result as far as

security goes, and should only be used under very special

circumstances.

Item Explanation

Disable Browser If this is selected, the CN8000A cannot be accessed

via a browser. It can only be accessed from the AP

programs (see AP Operation, page 133).

Disable HTTP If this is selected, the CN8000A can be accessed via a

browser, but not from an ordinary (HTTP) login

connection – it can only be accessed over a secure

HTTPS (SSL) connection.

Disable HTTPS (SSL) If this is selected, the CN8000A can be accessed via a

browser over an ordinary (HTTP) login connection, but

not via a secure HTTPS (SSL) connection.
