![Aten CN8000A [67/203] Security](/views2/1977360/page67/bg43.png)
5. Administration
53
Security
The Security page controls access to the CN8000A.
Login Failures
For increased security, the Login Failures section allows administrators to set
policies governing what happens when a user fails to log in successfully.
To set the Login Failures policies, check the Enable checkbox (the default is
for Login Failures to be enabled). The meanings of the entries are explained in
the table below:
Note: If you don’t enable Login Failures, users can attempt to login an
unlimited number of times with no restrictions. For security purposes,
we recommend that you enable this function and enable the lockout
policies.
Entry Explanation
Allowed Sets the number of consecutive failed log in attempts that are
permitted from a remote computer. The default is 5 times.
Timeout Sets the amount of time a remote computer must wait before
attempting to log in again after it has exceeded the number of
allowed failures. The default is 3 minutes.
Lock Client PC If this is enabled, after the allowed number of failures have been
exceeded, the computer attempting to log in is automatically
locked out. No log ins from that computer will be accepted. The
default is enabled.
Note: This function relates to the client computer’s IP. If the IP is
changed, the computer will no longer be locked out.
Lock Account If this is enabled, after the allowed number of failures have been
exceeded, the user attempting to log in is automatically locked
out. No logins from the username and password that have failed
will be accepted. The default is enabled.
