CN8000A User Manual
126
Starting Up
To bring up the Log Server, either double click the program icon, or key in the
full path to the program on the command line. The first time you run it, a screen
similar to the one below appears:
Note: 1. The MAC address of the Log Server computer must be specified in
the ANMS - Event Destination settings – see Log Server, page 47 for
details.
2. The Log Server requires the Microsoft Jet OLEDB 4.0 driver. See The
Log Server program does not run., page 178 if the program doesn’t
start.
The screen is divided into three components:
A Menu Bar at the top
A panel that will contain a list of CN8000A units in the middle (see The
Log Server Main Screen, page 131, for details).
A panel that will contain an Events List at the bottom
Each of the components is explained in the sections that follow.
