Aten CN8000A [197/203] Specifications
![Aten CN8000A [197/203] Specifications](/views2/1977360/page197/bgc5.png)
Appendix
183
Specifications
1
Power Over the NET
Function CN8000A
Connectors
Console Ports 1 x SPHD Male (Yellow)
KVM (Computer) Ports /
Virtual Media
1 x SPHD Female (Yellow)
Laptop USB Console
(LUC)
1 x USB Mini Type B Female (Black)
PON
1
1 x DB-9 Male (Black)
Modem 1 x DB-9 Male (Black)
LAN Ports 1 x RJ-45 Female
Power 1 x DC Jack
Switches
Reset 1 x Semi-recessed Pushbutton
LEDs
Power 1 (Orange)
Link 1 (Green)
10/100/1000 Mbps 1 (10 Mbps: Orange / 100 Mbps: Orange + Green / 1000
Mbps: Green)
Emulation
Keyboard / Mouse USB;PS/2
Video Up to 1920 x 1200 @ 60 Hz; DDC2B
Power Consumption DC 5.3V:4.79W:31BTU
Environmental
Operating Temperature 0° to 50° C (CN8000A)
0° to 40° C (Power Adapter)
Storage Temperature -20° to 60° C
Humidity 0 - 80% RH, Non-condensing
Physical Properties
Housing Metal
Weight 0.49 kg (1.08 lb)
Dimensions (L x W x H) 20.00 x 8.14 x 2.50 cm (7.87 x 3.20 x 0.98 in)
