Aten CN8000A [45/203] Administration
![Aten CN8000A [45/203] Administration](/views2/1977360/page45/bg2d.png)
31
Chapter 5
Administration
Introduction
Administration of the CN8000A using a web browser is divided into 3 sections:
Basic Settings, Advanced Settings, and Preferences. Each section is listed on
the sidebar with sub-menus that are used to configure the CN8000A’s
operating environment. This chapter discusses each of them in turn.
Note: 1. As you make your configuration changes in each section, click Apply
to save them.
2. Some configuration changes only take effect after the CN8000A is
reset. When those changes are made, a check is automatically put in
the Reset on Exit box (see Customization, page 70). To have the
changes take effect, log out and then log back in again.
3. If you don't have Configuration privileges (see User Management,
page 32), the Administration configuration dialogs are not available.
