![Aten CN8000A [20/203] System requirements](/views2/1977360/page20/bg14.png)
CN8000A User Manual
6
System Requirements
Servers
Servers are the computers connected to the switch via KVM Cables (see
Terminology, page xiv). The following equipment must be installed on these
servers:
A VGA, SVGA or multisync port
For USB KVM cable connections: Type-A USB port and USB host
controller
For PS/2 KVM cable connections: 6-pin mini-DIN keyboard and mouse
ports
Cables
A custom KVM cable set (USB; PS/2) to link the CN8000A to a server or
KVM switch is provided with this package.
Optional KVM cable sets in various lengths are also available. For the
types of cables available, please refer to the Compatible Cables section on
the product web page.
One custom console cable set to link the CN8000A to a local console is
provided with this package.
Note: This cable set has been designed to operate with either PS/2 or USB
consoles.
A USB cable for use with the Laptop USB Console (LUC) (see Laptop
USB Console (LUC), page 3) is provided with this package.
Cat 5e or higher Ethernet cable (not provided with this package), should be
used to connect the CN8000A to the LAN, WAN, or Internet.
