CN8000A User Manual
28
Sidebar Submenu
Sidebar Menu Description
Basic Settings
User Management- Create, Manage and set Permissions for
User Accounts.
Session- View and End current CN8000A user sessions.
Maintenance- Perform Backups, Restores, and Firmware
upgrades.
Advanced Settings
Device Information- View the CN8000A’s system information.
Network- Manage network settings.
ANMS- Manage Advanced Network Management Settings.
Security- Manage filters, policies, encryption, virtual Media,
and private certificate information.
Console Management- Configure serial port settings.
Date/Time- Set date and time information for the CN8000A.
Customization- Customize the CN8000A system settings.
Preferences
User Preferences- Set the current users default settings and
password.
Log- View event information logged for the CN8000A.
Remote Console- Provides a Remote Console Preview, Exit
Macro setup, and Power Management.
Download- Provides a link to install the Windows Client AP,
Java Client AP and Log Server AP.
About
Click this link to display the CN8000A’s firmware version, and
copyright information.
Viewer
Launches the Java or WinClient Viewer application for remote
server access.
Logout
Click this icon to log out and end your CN8000A session. For
security reasons, it is important to log out when your session
ends. Otherwise, if Disable Duplicate Login is checked, other
users must wait until the timeout setting has expired, and the sys-
tem logs you out, before the CN8000A can be accessed (see Dis-
able Duplicate Login, page 57).
