CN8000A User Manual
132
The List Panel
The List panel contains six fields:
The Tick Panel
The lower panel displays tick information for the currently selected CN8000A.
Note that if the installation contains more than one switch, even though a
switch isn’t currently selected, if its Recording checkbox is checked, the Log
Server records its tick information and keeps it in its database.
Field Explanation
Recording Determines whether the Log Server records log events for
this CN8000A or not. If the Recording check box is checked,
the field displays Recording, and log events are recorded. If
the Recording check box is not checked, the field displays
Paused, and log events are not recorded.
Note: Even though a CN8000A is not the currently selected
one, if its Recording check box is checked, the Log Server will
still record its log events.
Address This is the IP Address or DNS name that was given to the
CN8000A when it was added to the Log Server (see
Configure, page 127).
Port This is the port number that was assigned to the CN8000A
when it was added to the Log Server (see Configure,
page 127).
Connection If the Log Server is connected to the CN8000A, this field
displays Connected.
If it is not connected, this field displays Waiting. This means
that the Log Server's MAC address and/or port number has
not been set properly. It needs to be set in theANMS - Event
Destination settings (see page 46) and specified in the
Configure dialog box (see Configure, page 127).
Days This field displays the number of days that the CN8000A's log
events are to be kept in the Log Server's database before
expiration (see Configure, page 127).
Description This field displays the descriptive information given for the
CN8000A when it was added to the Log Server (see
Configure, page 127).
