Chapter 3. OSD Operation
23
it hasn’t obtained the address after one minute, it automatically
reverts to its factory default IP address (192.168.0.60.)
2. If the CN8000A is on a network that uses DHCP to assign network
addresses, and you need to ascertain its IP address, see IP Address
Determination, page 159, for information.
Disable Dev Authentication
Selecting Disable Dev Authentication will disable local login authentication on
the CN8000A. The switch can only be accessed using LDAP, LDAPS, MS
Active Directory, RADIUS or CC Management authentication. For more
information, see ANMS - Authentication, page 49.
Reset Default Values
Click Reset Default Values to use the default factory settings of the CN8000A.
Reset Certificate
Click Reset Certificate to use the Private Certificate settings of the CN8000A.
For more information, see Private Certificate, page 60.
Reboot
Click Reboot to power down and restart the CN8000A.
