7-6
Setup Mode
The Channel/Program (CH/PROG) Page
MIDI Program (MidiProg)
MidiProg denes which program number is transmitted out the MIDI Out port on the current
zone’s MIDI channel.
When you change the value of the Program parameter, the value of MIDIProg automatically
changes correspondingly. If you want to transmit a MIDI program change number dierent from
the one corresponding to the local program, select the local program rst, then change the MIDI
program.
Dierent programs are accessible depending on the value of the BankMode parameter:
Value of BankMode Available Programs
Ctl 0 or Ctl 32 0 to 127
Ctl 0/32 0 to 127
K2600 0 to 99
None None
Status
This parameter determines what the current zone does when you select the setup in Setup mode.
Muted means that the zone sends and receives program changes and entry/exit controller
values, but doesn’t play notes. If the value is Active, the zone sends and receives normally via
MIDI. Solo causes only the current zone to play, “backgrounding” all other zones (backgrounded
zones send and receive program changes and entry/exit controller values, but don’t play notes).
With a value of Solo+Muted, the current zone is both soloed and muted; when the zone isn’t
soloed, it won’t produce sound).
See the section about zone-status LEDs (page 7-2) for more information about muting and
soloing zones.
Out
Use the Out parameter to set the rear panel audio outputs used for each zone of the current
Setup. This parameter determines the output settings for the main program signal and insert
eects of each zone (for Aux eects output settings, use the Output parameter on the Setup Mode
AUX1 or AUX2 pages.)
A setting of Auto will make that zone output audio based on the settings for the program used by
that zone. Program output settings are set in the Program Editor using the Output parameter on
the top line of PROG FX page (see Output on page 6-48 for details) or the Output parameter on
the LAYER FX page (see page 6-49 for details.) A setting of Pri. (primary) will output track audio
to the MAIN Balanced Analog Outputs. A setting of Sec. (secondary) will output track audio to
the AUX Balanced Analog Outputs.
Input Channel
In Setup mode, an external MIDI device (such as a keyboard or sequencer) will play notes of a
single program by default (if the Local Keyboard Channel parameter is set to o, see page 10-10
for details.) The played program will be on a Zone that has a Channel parameter (on the CH/
PROG page) which matches the channel on which the external MIDI device is transmitting. (If no
Zone’s Channel parameter matches, the external device will play notes of the last program that
was using that channel in Program Mode or from a previously loaded Song or Setup.)
