Program Mode
The AMP Page
6-21
Hold Until Decay (TilDec)
When on, this parameter causes all notes in the layer to sustain through all three attack segments
in their amplitude envelopes even if the notes have been released. Looped amplitude envelopes
will not loop, however, if the notes are released before reaching the end of the nal attack
segment. Notes will go into their normal releases if they are released after the envelope has
looped. When set to O, notes will release as soon as a Note O message is generated.
The PITCH Page
Pressing the PITCH soft button takes you to the DSPCTL page with the Pitch function
highlighted. See The DSP Control (DSPCTL) Page on page 6-29 for more information on the Pitch
function.
The AMP Page
Pressing the AMP soft button takes you to the DSPCTL page with the Amp function (labeled as
“Level”) highlighted. See The DSP Control (DSPCTL) Page on page 6-29 for more information on
the Amp function.
