Master Mode
MAIN
11-5
MAPS
On the MAPS page you’ll nd parameters for setting keyboard behavior for velocity, pressure,
intonation, and key action maps. You can also set the default sequence for Song mode.
Velocity Map (Master)
Change the Master Velocity Map setting if you nd that the PC3A is not producing the desired
velocities (too loud or too quiet) based on your playing style (how light or heavy that you play
the keys.) The default map provides the widest range of velocity expression, but you may want
to choose a dierent map if the default does not suit your playing style.
The Master Velocity Map is an overall control for MIDI velocities used in the PC3A. MIDI
velocities are values created for each note depending on how hard you strike a key. The Master
Velocity Map aects MIDI velocity values for all MIDI sources and destinations used in the PC3A
(see the circled box above for its location in the MIDI signal ow.) Dierent maps used for the
Master Velocity Map generate dierent MIDI velocity values for the same physical key strike
velocity. Each map applies a dierent curve to received MIDI attack velocities and remaps them
PC3A Keyboard
KEY-VEL page for current Control Setup (in Program Mode) or current Zone (in Setup Mode)
Velocity Map Settings on Master Mode MAPS Page
VelocityMap Settings on MIDI Mode Transmit Page
MIDI Out via MIDI Out port or USB Computer port
PC3A Song Mode
MIDI In via MIDI In port or USB Computer port
PC3A Sound Engine
VelocityMap Settings on MIDI Mode Receive Page
to
PC3A audio outputs
MIDI
MIDI
Destinations
Sources
