![Kurzweil PC3A7 [43/423] Double button presses](/views2/2008894/page43/bg2b.png)
3-10
User Interface Basics
Navigation
Double Button Presses
Pressing two or more related buttons simultaneously executes a number of special functions
depending on the currently selected mode. Make sure to press them at exactly the same time.
In this mode
or editor…
…pressing these
buttons
simultaneously…
…does this:
Program mode
ARP, SW Brings up quick arpeggiator conguration page.
Octav-, Octav+ Reset MIDI transposition to 0 semitones. Double-press again to go
to previous transposition.
Chan/Layer Set current MIDI channel to 1. Sets layer 1 in Program editor.
Plus/Minus Step to next Program bank (increments of 128).
Up/Down cursor buttons Starts playback of demo song for current Program. Stop with Stop
transport button.
Left/Right cursor buttons Brings up the TEMPO page.
Setup mode
Plus/Minus Moves through list of Setups in increments of 128.
Chan/Layer Set zone 1.
Left/Right cursor buttons Brings up the TEMPO page.
Song mode
Up/Down cursor buttons Toggle between Play and Stop.
Chan/Layer Select all tracks on any TRACK page in Song Editor.
Left/Right cursor buttons Brings up the TEMPO page.
Storage mode
Left/Right cursor buttons Select all items in a list. Move cursor to end of name in naming
dialog.
up/down cursor buttons Clear all selections in a list. Move cursor to beginning of name in
naming dialog.
Program Editor
Chan/Layer Select Layer 1.
Any Editor
Plus/Minus Scroll through the currently selected parameter’s list of values in
regular or logical increments (varies with each parameter).
2 leftmost soft buttons Reset MIDI transposition to 0 semitones. Double-press again to go
to previous transposition.
Center soft buttons Select Utilities menu.
2 rightmost soft buttons Reset MIDI transposition to 0 semitones. Double-press again to go
to previous transposition.
Left/Right cursor buttons Display the TEMPO page.
Up/Down cursor buttons Toggle between Play and Stop of current song.
Cancel/Enter Panic (sends all notes/controllers off message on all 16 channels).
Save Dialog
Plus/Minus buttons Toggle between next free ID and original ID.
Rename Dialog
Plus/Minus buttons Moves cursor to the end of the name.
Left/Right cursor buttons Moves cursor to the end of the name.
