![Kurzweil PC3A7 [179/423] Real time control of arpeggiator parameters](/img/pdf.png)
Kurzweil PC3A7 [179/423] Real time control of arpeggiator parameters
![Kurzweil PC3A7 [179/423] Real time control of arpeggiator parameters](/views2/2008894/page179/bgb3.png)
Setup Mode
The Ribbon Conguration (RIBCFG) Page
7-53
With SyncType set to StopWait, if there is already something playing to sync to, the current
arpeggiator will wait for what is playing to stop before starting. This way you can trigger the
arpeggiator to start ahead of time, and have it start in sync at the release (stopping) of the ri,
arpeggiator, or song that you are syncing to. The dierence from Stop is that if there is nothing
playing to sync to, the arpeggiator will not start. This can be useful if you want to get your
arpeggiator ready to sync before you start whatever you are syncing it to. If the ri or song that
you are syncing to is already running, StopWait behaves just like Stop.
Num Beats
This aects the syncing of other arpeggiator or ri zones to the current zone, only if those other
zones have a SyncType setting of Downbeat or DownbeatWait. For zones being synced to the
current zone’s arpeggiator, this determines how many notes must be played by the current
zone’s arpeggiator before a downbeat occurs. By decreasing or increasing the value of the Num
Beats parameter, you can make zones with a SyncType setting of Downbeat or DownbeatWait
behave as if downbeats are occurring less or more frequently.
Real-time Control of Arpeggiator Parameters
You can have real-time control over several arpeggiator parameters, by assigning physical
controllers to special arpeggiator Controller Destinations. Any input (or entry value) from a
physical controller assigned to an arpeggiator Controller Destination overrides the programmed
values for the parameters of the arpeggiator on that controller’s zone. The override remains in
eect until you select a dierent setup (or a dierent program in Program mode.) Remember,
each of the following Controller Destinations aects only the arpeggiator for the zone which
your controller is assigned to.
Controller
Number
Corresponding
ARPEGGIATOR
Parameter
Operation
147 ArpOn Any controller value turns the Arpeggiator On.
148 ArpOff Any controller value turns the Arpeggiator Off.
150 ArpOrder Arpeggiator Order, each range of values selects one of
nine options in order of the parameters list: 0-14
(Played,) 15-28 (Upwards, etc.,) 29-42, 43-56, 57-70,
71-84, 85-98, 99-112, 113-127 (Simultaneous.)
151 ArpBeats Arpeggiator Beats, each range of values selects one of
seven options in order of the parameters list: 0-18
(Quarter notes,) 19-36 (8th notes, etc.,) 37-54, 55-72,
73-90, 91-108, 109-127(32nd triplets.)
152 ArpShift The 88 Arpeggiator Shift steps are scaled over the 128
MIDI controller values, so that 0 = 0 steps and 127 = 88
steps.
153 ArpLimit The 60 Arpeggiator Shift Limit steps are scaled over the
128 MIDI controller values, so that 0 = 0 steps and 127 =
60 steps.
154 ArpLmtOp Arpeggiator Shift Limit Option, each range of values
selects one of seven options in order on parameters list:
0-18 (Stop,) 19-36 (Reset, etc.,) 37-54, 55-72, 73-90,
91-108, 109-127 (FloatBip.)
