Storage Mode
Storage Mode Common Features
13-13
The following example shows how each dierent loading methods aect how four programs
load into a bank that already contains programs.
Example: Starting with the following objects already stored in the PC3A internal RAM:
Program ID Program Name
129 Piano Stack
133 Ole Upright 1
134 WestCoastPno&Pad
139 The Ancient
140 DancePnoEchplex
Suppose you were to load a le containing the following objects into the Base2 (129...256) bank:
Program ID Program Name
260 Brighter CP
261 TouchRezSynthCP
264 Inside Out CP
265 Pianet Classic
The following table shows the IDs that each program end up with when you load the programs
from the Classic Keys bank (255...384) into the Base2 bank:
Original
Program
ID
Program Name
Program IDs After Loading
OvFill Overwrt Merge Append Fill
129 Piano Stack Deleted Deleted 129 129 129
133 Ole Upright 1 Deleted Deleted Deleted 133 133
134 WestCoastPno&Pad Deleted Deleted Deleted 134 134
139 The Ancient Deleted Deleted 139 139 139
140 DancePnoEchplex Deleted Deleted 140 140 140
260 Brighter CP 129 260 133 135 130
261 TouchRezSynthCP 130 261 134 136 131
264 Inside Out CP 131 264 137 137 132
265 Pianet Classic 132 265 138 138 135
