7-40
Setup Mode
The Ribbon Conguration (RIBCFG) Page
eldtoMIDI22,theparameterwillautomaticallyalsouseMIDI54asasource,enablingthe768step
resolution when using the one section ribbon. The additional source that is automatically used will not be
seen in the Program Editor (this happens behind the scenes,) but both CC numbers will be sent to the MIDI
Out and USB port. (Also note, MIDI32 through MIDI63 are not available in the Program parameter
sourceelds,astheyarereservedforusingCCnumbers0-31asdescribedabove.)Whentheribbonisused
as a one section controller, if a MIDI CC above 63 is used as the destination for Sect1, only one CC number
will be sent and the ribbon will have a resolution of 128 steps. When the ribbon is used as a three section
controller, each section will only send one CC number and each section will have a resolution of 128 steps.
The Ribbon Conguration (RIBCFG) Page
Once you’ve selected a destination for the optional Ribbon controller, you can use the parameters
on the RIBCFG page to dene how the ribbons respond to nger position and pressure.
Parameter Range of Values Default
Ribbon Conguration One Section, Three Sections One Section
Position Mode Relative, Absolute Relative
Spring On, Off On
Center 0 to 127 64
Ribbon Conguration
You can use the Ribbon as one controller, or divide it up into three smaller sections, each with its
own controller assignments. Choose a value of One Section or Three Sections for the Ribbon
Conguration parameter. With Three Sections chosen, the page changes such that you can
adjust the parameters of each section:
