PC3A Objects (V 2.3)
Effect Chains
D-23
# Chain # Chain # Chain
666 Small Dark Room 717 Deep FuzzBass 1 764 ShortPnoRvb31
667 Snarcmp12 718 Eber Bass 765 St CHDly
668 Kickcmp13 719 SynFatener& Ech2 766 Synphase1
670 BeastieDrums 720 CP80Enhanc1 768 St CHDly
671 Clunker13 721 Fisher’sHarm Mic 771 Walrus EP
675 Funksnare9 722 AbbeyPianoHall2 772 EPChr16
676 Funksnare8 723 Medium Hall 2 773 Siberia
680 EPDistPhase1 724 Fagen Phaser 775 Deep Fuzz 5
681 RayEP 1 726 SmallWurly 780 Flange Echo 2
682 Deep Fuzz 1 727 Basic WurlyEP 781 ARPMosque Room
685 Deep Fuzz 31 729 Cheese Horns 782 Chr & Echo
687 ReverseVerb1 730 BasicChorusDly 2 784 Mutron Clav 2
690 Acidute 732 Wallower Ch 785 Siberia II
691 Blueman1 733 ChPanDlyComp 786 EnhanceComp1
692 CompDelay12 734 CheeseChorus 787 Shaper->Reverb2
694 SmallDarkRoom3 736 CompDelay 788 Clav Phase1
695 PlainComp15 737 SynFatener& Ech3 790 SynlaserFlange 1
696 RevComp4 738 BIGCompDelay 792 RockyRaccoon
697 EP RotoAmp12 739 UprightPiano 793 Squire
700 HiMutron 1 740 SitarCmpRvb 794 Flange 4
701 Sax Chamber 21 741 AC Bass 3 795 Deep Fuzz Clav
702 BigDarkRoomDW 742 VoxKB3 797 Clav Comp1
703 New Gtr 31 743 Blackfriday 798 SmallClav
704 PnoRvb 14 744 Blackestfriday 799 Synth Shimmer
705 Small Hall11 745 Flange 4 801 PhaseDly1
706 PnoRvb21 750 Good Leslie1 802 Shredlead1
707 Empty Stage 11 754 Good Leslie4 803 ThinphaseSweep
708 Mutron 2 756 GoodLeslie 6 804 EnvComp41
711 PlainComp12 757 WhitrShadeLeslie 805 MoogBASSComp11
713 CDR Synth 758 Inagadadavita 806 SynFatener& Ech4
714 SynthFlangenDely 759 GoodLordLeslie 807 Shredlead15
715 QuantzEnhanceSyn 760 Small HallComp1 808 PlainComp21
716 BladerunnrRvb 762 GoodLeslie 5 809 Garth
