Song Mode and the Song Editor
Song Mode: The MAIN Page
12-7
The track selected as the RecTrk will display an (R), designating it as the recording track. If the
RecTrk is set to Mult, initially all empty tracks will have Record (R) as a Track Status Indicator,
any of which can be switched back to empty (–) if at any time recording on specic tracks is not
desired.
If there isn’t a track with an (R), the RecTrk parameter’s value will be None. (The exception is
when the RecTrk is set to Mult and you have switched all of the tracks out of record enable.)
Track Channels
Each track has a MIDI Channel that it uses to receive and transmit data. By default, tracks 1–16 of
a new song are assigned to Channels 1–16 respectively, although a track can play or record on
any channel and the same channel can be used for more than one track. Keep in mind, however,
that only one program can be assigned to a channel at a time, so if you have more than one track
assigned to the same channel, they’ll play the same program—the one on the higher-numbered
track, since that’s the most recent Program Change command received on that channel.
Soft Buttons on the MAIN Page
This section contains descriptions of the functions of the function soft buttons, that is, the buttons
with labels not in all-caps. As with all other modes, the soft buttons in Song Mode that have
labels in all-caps call up dierent pages. See the following sections for descriptions on how these
pages work.
The Rec, Play, and Stop Soft Buttons
NOTE: These buttons are similar to the transport controls on a tape deck. Some of those decks require you
to press Play and Record simultaneously to begin recording. The PC3A’s transport buttons aren’t like that,
however. It’s important that you press only one of these soft buttons at a time to insure proper recording
start points, and to always be sure of the current sequencer status.
The Rec soft button changes the Song Status to REC. READY if the current Song Status is
STOPPED. If the current Song Status is PLAYING, it will be switched to RECORDING when you
press Rec.
The Play soft button plays back any recorded data when pressed while the song status is
STOPPED. Playback will begin from the bar and beat specied in the Locate parameter. When the
Song Status is REC READY, pressing the Play soft button will begin recording.
The Play soft button functions as a Pause button, but only when the Song Status is PLAYING or
RECORDING. Pressing Play while the song is playing will stop the playback, and the location
remains at the current bar and beat, allowing you to continue from that location by pressing Play
again.
Pressing Pause while recording will stop the recording process as if you had pressed Stop.
The Stop soft button halts the playback or recording, and resets the song’s location to either the
default Bar 1, Beat 1 value, or to whatever location you dened with the Locate parameter. If the
location is dened as something other than Bar 1, Beat 1, press Stop twice to reset to 1:1.
Pressing Stop when the Song Status is RECORDING will always prompt the “Save changes to
this song?” dialog (described below), and provides you with the opportunity to listen to the new
song and compare it with the old, previously saved, song before answering Yes or No.
The PC3A also has dedicated front panel buttons for Record, Play/Pause, and Stop. You’ll nd
them just below the eight mode buttons. Additionally you can control these functions from any
external sequencer that sends MIDI Machine Control (MMC) messages. The PC3A will
automatically listen to any MMC messages received at the USB or MIDI in port. The PC3A will
also automatically send its own MMC messages from the USB and MIDI out port, enabling the
