9-8
Effects and Effect Mode
Effects Overview
The Master Effects Page
NOTE: In Setup mode and Song mode, this page corresponds in appearance and function to the MASTER
EFFECTS page, which works on a per setup/song basis.
Pressing the MASTER soft button calls up the Master Eects page. The Master Eects page
contains the settings for the master EQ and Compressor. When enabled, the master eects are
applied to all programs in Program Mode. (In Setup and Song mode, each setup and song can have its
ownmastereectssettingsorusethemastereectssettingsfromEectmode,seeModebelowfordetails.)
The page appears as shown below:
Parameter Range of Values Default
Mode Master, Setup Master
Order Compressor => EQ, EQ => Compressor Compressor => EQ
Master FX Master FX Enabled, Master FX Bypassed Master FX Enabled
The two boxes in the chain on the Master Eects page are the master Compressor and EQ Eects.
Press the Edit button while either of these boxes is selected to edit the parameters for the box’s
eect. See Equalizers (EQ) on page 9-15 and Compressors, Expanders, and Gates on page 9-16 for
description on the EQ and Compressor parameters.
Mode
The setting for the Master Eects can be set directly on this page, or optionally in the control
setup. In Program mode, to set up the Master Eects from Eect mode, set the Mode parameter
to Master. To use the settings in the current control setup, select Setup. Controlling the Master
Eects from the control setup allows for convenient switching between dierent congurations.
See Control Setup on page 6-9 details. (In Setup and Song modes, a setting of Master uses the master
eectsettingssetinEectMode,whileasettingofSetupusesthemastereectssettingsforthecurrent
Setup or Song.)
Order
Use the Order parameter to determine the order of the two eects. Setting Order to Compressor
=> EQ routes signal through the Compressor rst, and then through the EQ. Setting Order to EQ
=> Compressor routes signal through the EQ rst, and then through the Compressor.
Master FX
The Master FX parameter determines whether the Master Eects are enabled or bypassed.
Setting Master FX to Master FX Enabled enables the Master Eects. Setting Master FX to Master
FX Bypassed bypasses the Master Eects, and eectively removes them from the signal path.
