6-48
Program Mode
The Program FX (PROGFX) Page
Insert
The Insert eect is the eects chain that is applied to the main audio bus.
Aux 1, Aux 2
The Aux eect is the eects chain that is applied to the selected auxiliary audio bus.
Output
The Output species the analog output to which the selected bus is routed. Setting the Output to
Main routes the signal of the selected bus to the main outputs. Setting the Output to Sec. routes
the signal of the selected bus to the auxiliary outputs.
Auxiliary Send Parameters
The Auxiliary Send parameters determines the level of the program signal sent to the auxiliary
eects chain.
Aux Send
The Aux Send parameter determines the level of the program signal sent to the auxiliary eects
chain.
Pre/Post Insert
The Pre/Post Insert parameter determines the point at which the auxiliary eect is applied to the
signal. When this parameter is set to Post, the PC3A applies the auxiliary eect to the signal
post-insert, i.e., after the insert eect has been applied. When this parameter is set to Pre, the
PC3A applies the auxiliary eect to the signal pre-insert.
To hear a program put through two eects in series (i.e., through two cascaded eects), choose
your desired eects for the Insert and either Aux (for whatever Aux you choose, the other should
be set to 0 None), set each bus’ Output to Main, and set the Aux Send parameter to either 0 dB or
100%. Then, set the Pre/Post Insert parameter to Post.
To hear a program put through two eects in parallel (i.e., through two distinct eects), choose
your desired eects for the Insert and either Aux (again, for whatever Aux you choose, the other
should be set to 0 None), set each bus’ Output to Main, and set the Aux Send parameter to either
0 dB or 50%. Then, set the Pre/Post Insert parameter to Pre.
With respect to each other, the Auxes are always in parallel, that is, they cannot be cascaded.
Type
The Type parameter determines how the selected wet aux signal (i.e., with eects applied) is
mixed into the nal signal. Additionally, it determines the units in which the Aux Send
parameter values are.
When Type is set to dB, the Aux Send parameter values are in units of decibels (dB). The value
specied in the Aux Send parameter is the amount of program signal sent to the aux eects chain.
To hear equal parts wet signal and dry signal (the signal with no eects applied) on the main
audio output, set the main Insert eect to 0 None and the Insert Output to Main, and set the Aux
1 eect to your desired eect and the Aux 1 Output to Main. Then, set the Aux1 Send to 0dB. If
you want only wet signal on the main audio output, set the main Insert Output to Sec.—keep in
mind that by this method, the dry signal is sent to the auxiliary audio outputs.
