Setup Mode
The Ribbon Conguration (RIBCFG) Page
7-55
Riffs
Ris are full songs or individual tracks of a song created in the PC3A’s Song mode that you can
trigger in setup mode. Standard MIDI les may also be imported to Song mode and then used as
ris in setups. Every zone in a setup can have it’s own ri—a completely independent sequence.
You can use a setup with many ris to trigger and stop looped sequences of dierent instrument
parts. Alternatively, a single ri can play multiple instrument parts. Each ri could be used as a
dierent song section of a backing track.
To use a ri, rst go to Song mode and note the ID# of the song, section of song and track that you
will use for your ri. Next go to Setup mode and create a setup. On the CH/PRG page of the
Setup Editor, choose the program that you want to use for the ri on the current zone. Program
changes that are recorded in song mode will be ignored when using the song as a ri in a setup.
You can also set up the playback event lter in Song mode to ignore other types of events as well.
Once you have selected your program, press the more soft button until you get to the RIFF1 and
RIFF2 pages. The following sections describe the contents of these pages.
Note: By default, setting a zone to trigger a ri will disable the ability to play notes of that zone’s
program from the keyboard. To re-enable this ability, see Local on page 7-59.
The RIFF1 Page
The rst Ri page appears as shown below, and has the following parameters:
Parameter Range of Values Default
Riff Off, On Off
Song Song List 0 None
Start
(Bar) (dependent on sequence) 1
(Beat) 1 to (dependent on time signature) 1
(Tick) 0 to 959 0
Stop
(Bar) (dependent on sequence) 2
(Beat) 1 to (dependent on time signature) 1
(Tick) 0 to 959 0
Transpose Off, On Off
Root Note C -1 to G9 C4
SrcTrack (Source Track) ALL, 1 to 128 ALL
Re Channel Off, On Off
