7-22
Setup Mode
Controllers
Controller
Number
Corresponding
Destination
Name
Description
5 PortTim Monophonic PC3A programs respond to this Controller if
portamento is turned on
6 Data Almost all PC3A programs have this Controller assigned to
lter frequency or brightness
7 Volume MIDI Volume
8 Balance MIDI Balance
9 MIDI 09
10 Pan MIDI Pan—programs which use the PANNER algorithm will
respond to real-time pan adjustments; all other programs will
respond on the next note start
11 Express MIDI Expression—Default assignment for CC Pedal 1. An
attenuator for fading in and out. It scales between minimum (0)
and the current value of Volume
12 MIDI 12
13 MIDI 13 Default assignment for Slider B
14 MIDI 14
15 MIDI 15
Controls pitchbend for AuxBend2. (see The BEND Page on
page 7-18)
16 Ctl A
17 Ctl B
18 Ctl C
19 Ctl D
20 MIDI 20
21 MIDI 21
Default destination for Ribbon, controls pitchbend for
AuxBend1. (see The BEND Page
on page 7-18)
22–28 MIDI 22–28 Default destinations for Sliders C to I
29 MIDI 29 Default destination for SW button
30, 31 MIDI 30, 31 MIDI Controllers 30, 31
32 Bank
33–63 33–63 MIDI Controllers 33–63
64 Sustain Default destination for Footswitch 1
65 MIDI 65
66 Sostenut
Default destination for Footswitch 2—holds notes that are
currently down, but not notes played subsequently (see
Sostenuto Pedal (SosPdl)
on page 6-20)
67 Soft
Default destination for Footswitch 3— lowers the volume by a
preset amount and may soften the timbre as well (see The
Footswitch Pages (FT SW1, FT SW2, FT SW3)
on page 7-36)
68 Legato Forces mono playback
69 Freeze Envelopes freeze at current state
Table 7-4 Controller Destination List
