Setup Mode
The Setup Editor
7-3
Table 7 gives you a quick visual reminder of how zones behave depending on their status.
LED Color
Zone
Status
Data Generated by Zone
Notes Controllers
Program
Number
Entry and
Exit Values
Red
Solo,
Solo+Muted
Yes Yes Yes Yes
Green (no others are red) Active
Yes Yes Yes Yes
Green (another is red) Backgrounded No No
Yes Yes
Orange Muted No No
Yes Yes
(Off) Empty No No No No
Table 7-1 Zone Status in Setup Mode
Remember that any changes you make to zone status in Setup mode are temporary; as soon as
you select another setup, that setup’s programmed zone status takes over. To change a setup’s
zone status permanently, use the Setup Editor (see Status on page 7-6).
Soloing a Zone
To solo a zone, set the Status parameter on the Setup Editor CH/PROG page (see The Setup Editor
and The Channel/Program (CH/PROG) Page below) to Solo. The Chan/Layer buttons—in addition
to scrolling through the zones of the current setup—now select the soloed zone. If you scroll
through zones 1-8, you will see the red solo LED moving across the bank buttons above the
sliders. After one zone is soloed, you can solo zones 1-8 by pressing on the corresponding Bank
button above the sliders; this action unsolos the previously soloed zone.
Additionally, you can congure a setup such that you can solo zones in real time (from outside of
the editor) by assigning a controller on the desired zone to destination 162 SoloZn. See Controllers
on page 7-19 for more information on controller destination assignments in Setup mode.
The Setup Editor
From Setup mode, press the Edit button to enter the Setup Editor, where you can make changes
to the currently selected setup. Use the soft buttons to select the various Setup Editor pages. The
upper line of each page displays the usual mode reminder, as well as the current Setup Editor
page, and the current zone. Use the Chan/Layer buttons to select one of up to sixteen dierent
zones, each having its own set of Setup Editor pages.
The parameters on the Setup Editor pages dene what each of a setup’s zones sends—both to
internal programs and to the MIDI Out port. They also determine how the PC3A responds to
MIDI signals received from a MIDI controller connected to the PC3A’s MIDI In port (when the
Local Keyboard Channel matches the transmit channel of your MIDI controller).
Compare
Pressing the Storage button calls up the Compare Editor, which recalls the setup pre-edit
settings, allowing you to compare your edited setup with the original setup. Pressing the Storage
button again returns you to the Setup editor. Using the Compare Editor makes no changes to the
current setup.
