Effects and Effect Mode
Effects Overview
9-3
The diagram below shows the signal paths for a multitimbral setup or song. The rst two zones
(or tracks in Song Mode) are diagramed as an example (represented by dark lines.) The 14
additional available zones (or tracks in Song mode) are represented by gray lines (labeled as Etc.)
Notice that each Program has its own Insert Chain, but all Programs share the same two Aux
Chains:
DSP Units - Manage and Distribute Processor Power for Effects
Each Eect Chain is composed of an eect-box or a series of eect-boxes. Each eect-box uses a
certain amount of the PC3A’s eects processing power, represented as a number of “DSP units.”
The number of DSP units used by an eect-box or Chain reects how complex the eect’s
algorithm is—more complex eects require more processing power. You can use up to 16 DSP
units at a time shared between all eects (except Master eects, which don’t use any DSP units.)
See TheEectsEnablePage on page 9-4 for details on how the PC3A automatically manages the
usage of DSP units (the default behavior,) and how you can override this behavior and manually
manage usage of DSP units.
Aux Override
Normally, in Program mode the Aux Eects Chains are specied by the program on the current
channel—or, in Setup mode and Song mode, by the program on the specied Aux Eects
channel. Aux override allows you to audition and select a new Aux chain without editing a
program. In Eects mode, the Setup Editor, or Song mode, press the AUXFX1 or AUXFX2 soft
buttons to set overrides for Aux Chain selection and other Aux Eects parameters. The Chain
specied for the Aux override is used instead of the chain of the current channel (or instead of the
specied Aux Eects channel in Setup and Song mode.) Also, send levels and other parameters
normally specied within individual programs can be set to xed values on the Aux Override
pages. See The Aux 1 Override and Aux 2 Override Pages on page 9-5 for details.
Insert
Program
Pre Post
Send Levels
Chain
Insert
Program
Pre Post
Send Levels
Chain
ZONE/TRACK 1
ZONE/TRACK 2
Etc.
AUX 2 Chain
AUX 1 Chain
Comp EQ
EQ Comp
Output
Master FX Order
S
S
S
