Effect Chains
D-22
# Chain # Chain # Chain
395 Cathedral Vx 450 SynthLead 489 HeavyBuckers
396 BurningTubes5 451 SynthBassAmp 491 ProBassComp
397 PunchBassAmp 452 MosqueySwirl 492 NYCTripStrings
399 RevverLeslie 454 PadFX2 493 ProBassComp2
400 Bradley’s Barn 1 455 PadFX1 496 DirtLordAmp
401 Bradley’s Barn 2 456 Chr & Echo 500 Setup Aux Verb
403 LA2A for Strings 457 Vocals w FX 501 Setup Aux DDL
411 ChrsDly 458 DrySynthCDR 517 Early Reection
412 RealDrmComp 459 WetSynthCDR 518 Pad Depth Pt1
414 RealDrmComp2 461 VibesRoom 519 Gunshot Verb
415 TiteDrmComp 462 PercussionRoom 520 AlphaCentauri 1
416 Marimba Hall 463 CagesRoom 521 BasicCDR
420 AGT Reverb 464 CmpRecitalHall 522 Synthorc BPM
422 WarmCruncher 465 StrRecitalHall1 523 BPM Flange Dly
424 Fierce Lead 466 StrRecitalHall2 524 DblSloFlangeCmp
425 CompTrem 467 RecitalHall 644 StevieTrem EP 1
426 12StWarmCrunch 468 MyJaco 645 Beater EP1
427 Phaser EGT 469 UprightBassRoom 646 Jamerson1
428 SnareComp1 470 Levin Chorus 648 SlyBASSComp1
430 KickComp1 472 Bright Room 651 Trampler 1
431 60’s BigDrumRoom 473 Med Dark Room 652 HipHop Drms1
434 AGT EnhCD 474 BasicReverb 654 HipHop Drms2
435 CDRecitalHall 477 Medium Hall 4U 655 TOP Drum Reverb1
436 Nylon EnhCD 478 KickComp2 656 HOP Drum Reverb1
439 ChrsDblRoom 479 ColdPliano 2 657 HopKickcmp1
440 EnhcBassAmp 480 FDR PercRoom 658 NoQuarter
441 FlangVoiceHall2 482 NylonAgtVerb 659 TechnoHHDly 1/8
442 Vocals w FXnMic 483 3BandDrumComp 660 HOP Drum Reverb3
445 Harpolicious 484 KikComp 4:1 661 HopKickcmp7
446 ChrsDly 485 ToxicStrings 662 Roomverb1
447 EGT Hall 486 3BandDrumComp2 663 Kickcmp6
448 Burning Tubes 487 Scoopd Dist EGT2 664 Snarcmp11
449 Chorus AGT 488 NotScoopd Dist 665 Reverb3
