Effects and Effect Mode
Effects Overview
9-23
LoResXcurs and HiResXcurs are the number of samples of delay to sweep through the resonator
at the rotation rate of each rotating speaker. The range is 0 to 510 samples.
ResH/LPhs sets the relative phases of the high and low resonators. The angle value in degrees is
somewhat arbitrary and you can expect the eect of this parameter to be rather subtle. The range
is 0 to 360.0 degrees.
Mic Angle is the angle of the virtual microphones in degrees from the “front” of the rotating
speaker. For the left microphone the angle increases clockwise (when viewed from the top), while
for the right microphone the angle increases counter-clockwise. Assigning a MOD to this
parameter should be done with caution: real-time adjustments to it will result in large sample
skips, which will cause clicks in the signal passing through. The range is 0 to 360.0 degrees. (In
Distort + Rotary only.)
The following parameters relate to rotation speed:
Speed sets the rotating speakers to run at either the slow rate or the fast rate.
Brake, when set to “On”, slows the rotating speakers to a halt.
Lo Mode, in the “Normal” setting, will give you full control of the low frequency speaker with
the Speed parameter. The “NoAccel” setting will hold the low frequency speaker at the slow
speed, and the Speed parameter will have no eect on its speed, though Brake will still work. In
the “Stopped” position, the low frequency speaker will not spin at all.
Lo Slow and Hi Slow are the rotation rates in hertz (Hz) of the speakers when Speed is set to
“Slow”.
Lo Fast and Hi Fast are the rotation rate in hertz (Hz) of the speakers when Speed is set to “Fast”.
LoSlow>Fst and HiSlow>Fst are the times for the speakers to accelerate from the slow speed to
the fast speed.
LoFst>Slow and HiFst>Slow are the times for the speaker to decelerate from the fast speed to
the slow speed.
LoAccelCrv and HiAccelCrv are the shapes of the acceleration curves for the speakers. 0% is a
constant acceleration. Positive values cause the speaker to speed up slowly at rst then quickly
reach the fast rate. Negative values cause a quick initial speed-up then slowly settle in to the fast
speed. If set to a low negative value, it will overshoot.
LoSpinDir and HiSpinDir are the directions of rotation of the speakers. The choice is clockwise
(CW) or counter-clockwise (CCW).
Vibrato/Chorus
The Vibrato/Chorus eect simulates the vibrato and chorus eects on a tone wheel organ, and is
used in conjunction with the Rotary Speaker. It has several unique parameters:
VibChInOut is an in/out switch for the Vibrato/Chorus eect.
Vib/Chor is the type of Vibrato/Chorus eect to be used. The choices are from three vibratos,
“V1”, “V2”, “V3”, or three choruses, “C1”, “C2”, “C3”.
