MIDI Mode
The RECEIVE Page
10-9
System Exclusive ID (SysExID)
The SysExID parameter dierentiates between more than one MIDI device of the same model.
You won’t need to change the default setting of 0 unless you have multiple PC3As (or K2600s,
K2500s, or K2000s) receiving SysEx messages from a single source. In that case, make sure each
instrument has a dierent SysExID. Then you can direct SysEx messages to the appropriate PC3A
with the SysExID byte that’s included with every SysEx message. A value of 127 species “Omni
Receive.” That is, at this value, a PC3A responds to a SysEx message regardless of the SysEx ID of
the message.
Bank Select
BankSelect allows you to choose between having the PC3A respond to Controller 0 or Controller
32 or both. The reason for this is that various manufacturers have chosen one method or the
other. The three possible values for this parameter are:
Ctl 0 Responds to controller 0 only.
Ctl 32 Responds to controller 32 only.
Ctl 0/32 Responds to 0 or 32.
