Storage Mode
Export
13-15
Export
Press the EXPORT soft button to go to the Export page. The Export page allows you to export
MIDI les created in Song mode, lists of controller assignment info that are automatically created
for each Program and each Chain, or a list of all objects in text format. Developers can also export
an object in XML format, or export a KPN.
To export a MIDI le created in Song mode, the song must be currently loaded in Song mode. Go
to Song mode and load the desired song, then return to the Storage mode EXPORT page and
press the Song soft button. You will be prompted rst to choose a directory to save the le into,
and then you will be prompted to name the MIDI le. When you name the le, you can use the
Type eld to choose to export either a Standard MIDI File type 1 (saves with multiple channels,)
or Standard MIDI File type 0 (saves all channels as 1 channel.)
To export a list of controller assignment info for all Programs or for all Chains, press the PrInfo
soft button or the FXInfo soft button. You will be prompted to choose a directory to save into, and
then you will be prompted to name the info le. A comma separated value le will be exported.
To export a list of all objects in text format, press the ObjLst soft button. You will be prompted to
choose a directory to save into, and then you will be prompted to name the le. A comma
separated value text le will be exported, listing each object type with ID number, object name,
and whether the object is internal or user.
To export an object in XML format, press the ObjFmt soft button. Choose an object from the list
using the Alpha Wheel, -/+ buttons, or the alphanumeric pad, then press the Ok soft button. You
will be prompted to choose a directory to save into, and then you will be prompted to name the
le.
To export a KPN, press the KPN soft button. Choose a Domain and Channel, then press the Ok
soft button. You will be prompted to choose a directory to save into, and then you will be
prompted to name the le.
Format
USB devices come formatted and ready to use with the PC3A. If you ever need to format a device,
however, you can use any computer with USB device formatting capability, or format it using the
PC3A.
To format a USB device with the PC3A, plug the USB device into the PC3A’s USB Storage port,
then press the Storage button to enter Storage mode. Press the soft button labeled Format. The
PC3A will ask you if you want to format. Press the OK soft button to format the device, or the
Cancel soft button to return to the Storage mode main page.
Caution: Formatting will erase all les on the USB device, make sure anything that you wish
to save is backed up on another device.
