12-16
Song Mode and the Song Editor
Song Mode: The Filter Pages (RECFLT and PLYFLT)
LoVel
LoVel determines the lowest note on/o velocity that is recorded/played back when Notes is set
to On.
Hi
The Hi to the right of LoVel determines the highest note on/o velocity that is recorded/played
back when Notes is set to On.
Controllers
With Controllers set to O, all controllers are ignored during recording/playback. With
Controllers set to On, controller data only of the specied controller and only within the specied
value range are recorded/played.
Controller
The Controller parameter determines which controller(s) is/are recorded/played back when
Controllers is set to On.
LoVal
LoVal determines the lowest value for the specied controller that is recorded/played back when
Controllers is set to On.
Hi
The Hi to the right of LoVal determines the highest value for that specied controller that is
recorded/played back when Controllers is set to On.
PitchBend
This parameter enables/disables pitch bend events to be recorded/played back.
ProgChange
This parameter enables/disables program changes to be recorded/played back—this includes
Controllers 0 and 32 (bank change).
MonoPress
This parameter enables/disables monophonic key pressure events to be recorded/played back.
PolyPress
This parameter enables/disables polyphonic key pressure events to be recorded/played back.
The Rec, Play, and Stop Soft Buttons
These soft buttons function as described in The Rec, Play, and Stop Soft Buttons on page 12-7.
The Done Soft Button
If no changes were made in the RECFLT/PLYFLT page, pressing the Done soft button calls up
the MAIN page. If changes were made, pressing the Done soft button calls up the “Save
Changes” dialog.
