Quick Access Mode
The QA Editor
8-3
Selecting A Setup For A Quick Access Entry
If you want to store a setup in the current entry instead of a program, press the Type soft
button—when you do this, notice that the Type eld change from Program to Setup (also notice
that the channel indicator disappears, since setups can transmit over several channels). The list of
objects changes from the program list to the setup list. Just as with programs, the cursor
highlights the setup’s ID and name. Use the Alpha Wheel or -/+ buttons to scroll through the
setups. You can also use the alphanumeric pad followed by the Enter button to choose a Setup by
ID#.
Keep in mind that you can have both setups and programs in the same QA bank.
Naming And Saving A Quick Access Bank
When you’ve lled each entry with the object you want, press the Name soft button if you want
to rename the bank, or press the Save soft button to begin the save procedure. Or, press the Exit
button to exit the QA editor, and the “Save Changes?” dialog comes up.
