Zoom F1-SP [12/73] Inserting microsd cards

Inserting microSD cards

Turn the power o and then open the microSD card slot cover.

Insert the microSD card into the card slot.

To remove a microSD card, gently push it further into the slot and then pull it out.

Close the microSD card slot cover.

NOTE

• Always make certain that the power is o when inserting or removing a microSD card. Inserting or removing a

card while the power is on could result in data loss.

• When inserting a microSD card, be sure to insert the correct end with the top side up as shown.

• Recording and playback are not possible when a microSD card is not loaded in the

• To format a microSD card, see "Formatting microSD cards".
