Zoom F1-SP [62/73] Other functions

Other functions

Formatting microSD cards

A microSD card that has been purchased or formatted by a computer should be reformatted for use with the

While pressing , press to open the MENU screen.

Use and to select "SD Card", and press .

Use and to select "Format", and press .

Use and to select "Execute", and press .
