Zoom F1-SP [60/73] Setting the type of battery used

Setting the type of battery used

Set the type of battery used so that the amount of remaining battery charge can be accurately displayed.

While pressing , press to open the MENU screen.

Use or to select "Battery", and press .

Use and to select the battery type, and press .
