Zoom F1-SP [58/73] Setting the display backlight
![Zoom F1-SP [58/73] Setting the display backlight](/views2/2009588/page58/bg3a.png)
Setting the display backlight
You can set the display backlight to turn o after a specic amount of time without use.
1.
While pressing , press to open the MENU screen.
2.
Use and to select "LCD", and press .
3.
Use and to select "Backlight", and press .
4.
Use and to set the amount of time until the backlight turns o, and press .
HINT
This can be set to O, On, 30 seconds, or 1 to 5 minutes.
57
