Zoom F1-SP [45/73] Using as an audio interface

Using as an audio interface

input signals can be input directly to a computer, iOS device or other equipment, and playback signals on a

computer, iOS device or other equipment can be output from the

Press or on the USB screen to select "Audio I/F", and press .

Use or to select the type of device, and press .

NOTE

After selecting "iOS", turn the

power on, follow the instructions on screen, and disconnect the cable once.

Then, select "iOS" again and reconnect the cable.

After selecting PC/Mac, use or to select the power source, and press .

The following power sources can be selected.
