Zoom F1-SP [24/73] Connection examples
![Zoom F1-SP [24/73] Connection examples](/views2/2009588/page24/bg18.png)
Connection examples
Recording is possible in a variety of situations like these.
■
Recording video while using a lavalier mic
Record sound of performer with lavalier mic connected to the MIC/LINE IN jack.
Lavalier mic
MIC/LINE IN
jack
■
Recording video
Record sound of main subject with shotgun mic capsule connected to the .
Connect the
PHONE OUT jack to the camera mic input.
Mic input
PHONE OUT jack
HINT
When connecting the
to the camera, calibrate the levels of both devices by using the built-in test tone.
(
→
"Adjusting connected equipment levels (playing test tones)").
23
