Turning the power on/o
Turning the power on
1.
Slide toward until the Home Screen appears on the display.
NOTE
• The rst time you turn the power on after purchase, you must set the language (
→
"Setting the language
shown") and the date/time (
→
"Setting the date and time").
• If “No SD Card!” appears on the display, conrm that a microSD card is inserted properly.
• If “Invalid SD Card!” appears on the display, the card is not formatted correctly. Format the microSD card
(
→
"Formatting microSD cards") or use a dierent microSD card (
→
"Inserting microSD cards").
Turning the power o
1.
Slide toward .
NOTE
Keep sliding the switch until "Power o" appears on the display.
12
