![Zoom F1-SP [29/73] Recording](/views2/2009588/page29/bg1d.png)
Recording
Adjusting input levels
Adjust the recorded level of signals coming in to the .
HINT
• Adjust so that the peak level stays around −12 dB.
• Plug-in power can be supplied by the MIC/LINE IN jack as well as by the MIC/LINE IN jack of a connected mic
capsule (
→
"Setting plugin power").
• If the sound distorts even when you lower the input level, try changing mic positions and adjusting the output
levels of connected devices.
• To cut noise from wind and other sources during recording, see "Reducing noise".
• To stop input signal clipping, see "Setting the limiter".
NOTE
Lower the input level if the REC LED ashes.
When using a mic capsule
1.
Turn on the mic capsule to adjust the input level.
28
