Zoom F1-SP [36/73] Capturing audio before recording starts pre rec

Capturing audio before recording starts (PRE REC)

The input signal can be captured for about 2 seconds before is pressed. This is useful when a performance

starts suddenly, for example.

While pressing , press to turn on Pre Rec.
