Zoom F1-SP [25/73] Setting plugin power

Setting plugin power

Use this setting when a mic that is compatible with plug-in power is connected to the MIC/LINE IN jack or

to the MIC/LINE input jack of a mic capsule connected to the

While pressing , press to turn it ON.
