Zoom F1-SP [19/73] The following date formats can be used

Use and to select "Date Format", and press .

Use and to select the date format, and press .

The following date formats can be used.

Setting value Explanation

YYMMDD Year, month, day order

MMDDYY Month, day, year order

DDMMYY Day, month, year order
