Zoom F1-SP [32/73] Reducing noise

Reducing noise

This function can reduce low-frequency noise, including wind and vocal pops.

Press to set the cuto frequency.

HINT

Select OFF or 80 Hz, 120 Hz or 160 Hz as the frequency.
