Zoom F1-SP [21/73] Connections
![Zoom F1-SP [21/73] Connections](/views2/2009588/page21/bg15.png)
Connections
Attaching to a camera
Connecting the shock mount
This reduces noise when the is mounted on a digital SLR camera.
1.
Attach the ends of two arms from the shock mount to one belt loop on the .
2.
Attach the other arms to the other belt loop, one at a time.
Using the elasticity of the arms, attach their ends to the belt loops while bending them slightly.
1
2
Arms (2 each on left and right)
3.
Slide the shock mount onto the camera accessory shoe and tighten the screw to attach it.
20
