Zoom F1-SP [23/73] Connect the lavalier mic to the mic line in jack and tighten the screw lock
![Zoom F1-SP [23/73] Connect the lavalier mic to the mic line in jack and tighten the screw lock](/views2/2009588/page23/bg17.png)
3.
Connect the lavalier mic to the MIC/LINE IN jack, and tighten the screw lock.
HINT
• This jack can provide plug-in power to mics that use it. (
→
"Setting plugin power")
• Mics without screw locks can also be connected to the MIC/LINE IN jack.
