Zoom F1-SP [55/73] Setting how the counter is displayed

Setting how the counter is displayed

The counter shown during recording can be set to either the elapsed recording time or the remaining possible

recording time.

While pressing , press to open the MENU screen.

Use and to select "Record/Play", and press .

Use and to select "Rec Counter", and press .

Press or to select how it is shown, and press .
