Zoom F1-SP [20/73] Preventing misoperation

Preventing misoperation

In order to prevent misoperation while recording, the hold function can be used to disable the buttons on the

NOTE

This can be set to automatically disable button operation only during recording.

(

→

"Automatically disable buttons during recording")

Activating the HOLD function

Slide to HOLD.

Deactivating the HOLD function

Slide back to the middle.
