14
GRINDING
Grinding wheel, cup-type grinding wheels, ap wheels, wheels with
abrasive bre, wire brushes and exible discs, etc. should be used for
grinding. Each type of discs and workpiece requires proper working
method and personal protective equipment.
Cut-o wheels should not be used for grinding.
Grinding discs are intended for removal of material with an edge
of the disc.
• Do not use the lateral surface for grinding. The optimum
working angle for this disc type is 30° (g. H).
• Works related to grinding can be performed only, when proper
grinding discs are used for a given workpiece.
When ap wheels, discs with abrasive bre and exible discs for
sandpaper are used, attention should be paid to the proper tool
angle (g. I).
• Do not grind with the entire surface of a wheel.
• This disc type should be used for working at surfaces.
Wire brushes are mainly used for cleaning sections and hard-to-
reach spaces. They can be used to remove rust, painting coats, etc.
from a workpiece surface (g. K).
Only such working tools can be used, whose permissible
rotational speed is higher or equal to the maximum no load speed
of the grinder.
OPERATION AND MAINTENANCE
Before any operations related to installation, adjustment, repairs
or maintenance are commenced, the plug of the power cord
should be disconnected from the socket.
MAINTENANCE AND STORAGE
• It is recommended to clean the tool after each use.
• Do not use water or other uids for cleaning.
• The tool should be cleaned with a dry piece of cloth or blown with
compressed air of low pressure.
• Do not use any cleaning agents or solvents, since they may
damage plastic parts.
• Venting slots in the motor housing should be cleaned on a regular
basis not to overload the tool.
• When the power cord is damaged, it should be replaced with
the power cord of the same parameters. It should be performed
by a qualied professional or the tool should be delivered to an
authorised service shop.
• When the commutator sparks excessively, have the condition of
motor carbon brushes checked by a qualied person.
• The tool should be always stored in a dry place and out of reach
of children.
REPLACING THE CARBON BRUSHES
Worn (shorter than 5 mm), burnt or cracked motor carbon brushes
should be immediately replaced. Both carbon brushes should be
always replaced at the same time.
Carbon brushes should be replaced by a qualied person using
original spare parts only.
All types of faults and defects should be eliminated by an authorised
service of the manufacturer.
SPECIFICATIONS
RATED DATA
Angle Grinder 59G175
Parameter Value
Power supply voltage 230 V AC
Power supply frequency 50 Hz
Rated power 750 W
Rotational speed adjustment range 3000-12000 min
-1
Max. grinding wheel diameter 125 mm
Inner disc diameter 22,2 mm
Spindle thread M14
Protection class II
Weight 1,8 kg
Year of manufacture 2020
59G175 denes type and indication of the device
NOISE AND VIBRATION DATA
Information regarding noise and vibration
The following levels of emitted noise, such as emitted acoustic
pressure Lp
A
and acoustic power level Lw
A
and measurement
uncertainty K have been given in the instruction manual as dened
in the EN 60745 standard.
The following vibration value (acceleration value) a
h
and
measurement uncertainty K have been determined as dened in the
EN 60745 standard.
The vibration level provided in this instruction manual have been
determined according to the measurement procedure as dened in
the EN 60745 standard and can be used for comparison of power
tools. This can be used for preliminary assessment of exposure to
vibrations.
The provided vibration level is representative for main applications
of the power tool. If the power tool is used for other applications or
with other working tools, and if it is not suciently maintained, the
vibration level may vary. The aforementioned reasons may increase
the exposure to vibrations during the entire operating period.
In order to precisely estimate the exposure to vibrations, periods
should be accounted for, in which the power tool is switched o, or
when it is switched on, but not operated. Thus, the total exposure to
vibration may prove considerably lower.
Additional safety measures should be taken to protect the user
against eects of vibrations, such as: maintenance of the power tool
and its working tools, ensuring proper temperature of the hands and
proper organisation of work.
NOISE LEVEL AND VIBRATION PARAMETERS
Sound pressure (cutting) Lp
A
= 82,9 dB (A) K=3dB (A)
Sound pressure (grinding) Lp
A
= 83,4 dB (A) K=3dB (A)
Sound power (cutting) Lw
A
= 93,9 dB (A) K=3dB (A)
Sound power (grinding) Lw
A
= 94,3 dB (A) K=3dB (A)
Vibration acceleration (cutting/additional handle) a
h
= 2,119 m/s
2
K=1,5 m/s
2
Vibration acceleration (grinding/additional handle) a
h
= 1,617 m/s
2
K=1,5 m/s
2
Vibration acceleration (cutting/main handle) a
h
= 2,978 m/s
2
K=1,5 m/s
2
Vibration acceleration (grinding/main handle) a
h
= 2,565 m/s
2
K=1,5 m/s
2
ENVIRONMENTAL PROTECTION
Electrical equipment must not be disposed o with household
waste and, instead, should be utilized at appropriate facilities.
Information on utilization can be provided by the product
vendor or the local authorities. Waste electrical and electronic
equipment contains substances that are not neutral to
the natural environment. Equipment that is not recycled
constitutes a potential hazard to the environment and to
human health.
* Right to introduce changes is reserved.
“Grupa Topex Spółka z ograniczoną odpowiedzialnością” Spółka komandytowa with seat in Warsaw at
ul. Pograniczna 2/4 (hereinafter Grupa Topex) informs, that all copyrights to this instruction (hereinafter
Instruction), including, but not limited to, text, photographies, schemes, drawings and layout of the
instruction, belong to Grupa Topex exclusively and are protected by laws accordingly to Copyright
and Related Rights Act of 4 February 2004 (ustawa o prawie autorskim i prawach pokrewnych, Dz. U.
2006 No 90 item 631 with later ammendments). Copying, processing, publishing, modications for
commercial purposes of the entire Instruction or its parts without written permission of Grupa Topex
are strictly forbidden and may cause civil and legal liability.
