1-8 GENERAL INFORMATION
General Specifications
Items KLE500-B1
Dimensions
Overall Length 2 215 mm (87.2 in.)
Overall Width 880 mm (34.6 in.)
Overall Height 1 270 mm (50.0 in.)
Wheelbase 1 500 mm (59.0 in.)
Road Clearance 180 mm (7.09 in.)
Seat Height 850 mm (33.5 in.)
Dry Weight 181 kg (399 lb.)
Curb Weight:
Front 95 kg (209 lb.)
Rear 105 kg (232 lb.)
Fuel tank Capacity 15 L (4.0 US gal.)
Performance
Minimum Turning Radius
2.4 m (7.9 ft.)
Engine
Type 4-stroke, DOHC, 2-cylinder
Cooling System Liquid-cooled
Bore and Stroke 74.0 × 58.0 mm (2.91 × 2.28 in.)
Displacement
498 mL (30.39 cu in.)
Compression Ratio
9.8:1
Maximum Horsepower
33 kW (44.9 PS) @8 300 r/min (rpm)
Maximum Torque 41 N·m (4.2 kgf·m, 30 ft·lb) @7 500 r/min (rpm)
Carburetion System Carburetors, Keihin CVK34 × 2
Starting System Electric starter
Ignition System Battery and coil (transistorized)
Timing Advance Electronically Advanced (digital)
Ignition Timing From 10° BTDC @1 300 r/min (rpm) to 35° BTDC
@5 000 r/min (rpm)
Spark Plugs NGK DR9EA or ND X27ESR-U
Cylinder Numbering Method Left to right, 1-2
Firing Order 1-2
Valve Timing:
Inlet
Open 27° BTDC
Close 47° ABDC
Duration 254°
Exhaust
Open 52° BBDC
Close 22° ATDC
Duration 254°
Lubrication System Forced lubrication
