ENGINE LUBRICATION SYSTEM 7-7
Specifications
Item Standard
Engine Oil
Grade API SE, SF, SG or
API SH or SJ JASO MA
Viscosity SAE 10W-40
Capacity 2.8 L (when filter is not removed)
3.0 L (when filter is removed)
3.4 L (when engine is completely dry)
Level Between upper and lower l evel lines
Oil Pressure Measurement
Oil pressure @4 000 r/min (rpm), oil
temperature 90°C (194°F)
275 ∼ 335 kPa (2.8 ∼ 3.4 kgf/cm², 40 ∼ 48 psi)
