12-6 BRAKES
Specifications
Item Standard Service Limit
Brake Lever, Brake Pedal
Brake Lever Position
4-way adjustable (to suit rider)
–––
Brake Pedal Position 30 ∼ 40 mm (1.2 ∼ 1.6 in.) below footpeg top –––
Free Play Non-adjustable –––
Brake Pad Thickness
Front 5.5 mm (0.22 in.) 1 mm (0.04 in.)
Rear 4.5 mm (0.18 in.) 1 mm (0.04 in.)
Brake Disc Thickness
Front 4.8 ∼ 5.1 mm (0.19 ∼ 0.20 in.) 4.5 mm (0.18 in.)
Rear 4.8 ∼ 5.1 mm (0.19 ∼ 0.20 in.) 4.5 mm (0.18 in.)
Brake Disc Runout
0.1 mm (0.004 in.) 0.2 mm (0.008 in.)
Brake Fluid
Grade DOT4
